- Country
- Great Britain (UK)
- Manufacturer / Brand
- Electric Audio Reproducers (EAR); London, Isleworth
- Year
- 1962 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 167554
Picture courtesy of guest Stewart Evans
Picture courtesy of guest Stewart Evans
Picture courtesy of guest Stewart Evans
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Dry Batteries / 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Autobat - Electric Audio Reproducers EAR
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
Battery operated (6 x U2) transistor record player.
- Source of data
- -- Schematic
- Literature/Schematics (1)
- Radio And Television Servicing books (R&TVS)
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
- Other Models
-
Here you find 19 models, 10 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Electric Audio Reproducers (EAR); London, Isleworth
Forum contributions about this model: Electric Audio: Autobat
Threads: 2 | Posts: 2
May I respectfully point out that the pictures shown are not of the Autobat, but are of a totally different model. The Autobat, as it's name implies was a battery operated record player fitted with a BSR UA14 Autochanger powered by a 9v DC Motor. It incorporated a Transistor amplifier and a 6" (152mm)diameter round full range speaker, and was powered by 6 x 'U2' ('D') Cells. A seperate amplifier and speaker, also powered by 6 'D' Cells, and connecting cable using Phono (RCA)Connectors allowed for the reproduction of Stereo Records. A BSR TC8S Stereo Crystal cartridge was fitted. Tow versions of the 'Autobat' were made, one also incorporating an AM (MW/LW) Manually tuned radio. Pictures of the latter are included with this posting
