• Country
• United States of America (USA)

• Manufacturer / Brand
• Electro-Brand Inc.; Westchester, IL / Chicago, IL

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 300575

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Line / Batteries (any type) / 60 Hz; 110 - 120 / 4 x C 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Power out
• 0.45 W (max.)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Solid State EB-2330 - Electro-Brand Inc.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 11.375 x 8 x 4 inch / 289 x 203 x 102 mm

• Notes

• Band	Frequency
  AM	540 - 1600 kHz
  FM	88 - 108 MHz
  Aircraft	108 - 140 MHz
  PBH	145 - 176 MHz
  PBL	30 - 50 MHz
  Weather	162.55 MHz

  Made in Hong Kong.

• Author
• Model page created by Aldo Andreani. See "Data change" for further contributors.
