Georgian 4-Way Speaker System
Electro-Voice Inc.; USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Electro-Voice Inc.; USA
- Year
- 1956 ??
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 98571
-
- Brand: Buchanan
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- Presumably Dynamic Loudspeaker (moving coil)
- Material
- Various materials
- from Radiomuseum.org
- Model: Georgian 4-Way Speaker System - Electro-Voice Inc.; USA
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 34 x 53 x 26 inch / 864 x 1346 x 660 mm
- Notes
- Complete 4-way speaker system, divides the audio spectrum into low-bass section, mid-bass section, treble section and very high range.
Uses Klipsch K folded corner horn with 15WK LF driver, 848HF coaxial mid-bass and treble, T35 super-tweeter.
35W, 70W peak
- Net weight (2.2 lb = 1 kg)
- 130 kg / 286 lb 5.5 oz (286.344 lb)
- Price in first year of sale
- 825.00 $
- Literature/Schematics (1)
- Allied Radio Catalog Nº 150, 1956
