Amplifier PA-200
Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)
- Country
- Canada
- Manufacturer / Brand
- Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)
- Year
- 1953 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 308557
From an Electrohome advertisement.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 10 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Amplifier PA-200 - Electrohome Dominion
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 11 x 7 x 7 inch / 279 x 178 x 178 mm
- Notes
-
The Electrohome PA200 is a 6-tube audio amplifier. Has input for crystal or magnetic phono pickups. Volume, bass and treble controls. For 4, 8 or 16 ohm speaker. Removable front panel for custom installations.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Supplement 31)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
