Universal Power Supply (Labornetzgerät) EA-4000B-4.5

Elektro-Automatik (EA); Viersen

Data
Forum
Pictures
Collections

  • Year
  • 2007 ??
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 263735

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Universal Power Supply EA-4000B-4.5 - Elektro-Automatik EA; Viersen
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 480 x 128 x 195 mm / 18.9 x 5 x 7.7 inch
  • Notes

  • Kombination aus Trenn-Stelltrafo, Trenntrafo, Gleichspannungsregler und Festspannungsnetzteil.
    Ausgänge: AC: 0...130V/130V...260V(3A), 230V(2A), 3/12/18/24V(2A); DC: 0...32V(0...5A), 3...6V(2A).

    Made in China.

  • Net weight (2.2 lb = 1 kg)
  • 30 kg / 66 lb 1.3 oz (66.079 lb)
  • Price in first year of sale
  • 1,084.00 Euro
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Michael Mischke. See "Data change" for further contributors.
