Комбинированный прибор Ц4312 Multimeter C4312

• Country
• Soviet Union

• Manufacturer / Brand
• Elektroizmeritel, Zhitomir, SU (soviet union)

• Year
• 1976

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 318426

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 4,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Комбинированный прибор Ц4312 Multimeter C4312 - Elektroizmeritel, Zhitomir,

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 115 x 81 x 215 mm / 4.5 x 3.2 x 8.5 inch

• Notes

• Accuracy class: AC 1.5, DC  1.0

  Resistance: 1 %

  ACV/DCV 0.3 ... 900 V in 9 ranges
  ACA/DCA 0,3 mA ... 6 A in 9 ranges
  Resistance Ω x1 ... MΩ x30 in 5 ranges

• Net weight (2.2 lb = 1 kg)
• 1.114 kg / 2 lb 7.3 oz (2.454 lb)

• Price in first year of sale
• 43.00 RUB

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
