Orivohm II. 1341/E - TR-1401 new

• Country
• Hungary

• Manufacturer / Brand
• EMG, Orion-EMG, Elektronikus Mérökészülélek Gyára; Budapest

• Year
• 1970–1972 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 159951

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECC82 ECC82 EZ80

• Number of Transistors

• Semiconductors
• GDK-1

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Orivohm II. 1341/E - TR-1401 [new] - EMG, Orion-EMG, Elektronikus M

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 236 x 180 x 145 mm / 9.3 x 7.1 x 5.7 inch

• Notes
• • U_DC: 3 - 1000V
  • U_AC: 3 - 300V (30Hz - 25MHz)
  • R: 1Ω-1Ω

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
