Wide Band V.T. Voltmeter 1324 / TR-1301

EMG, Orion-EMG, Elektronikus Mérökészülélek Gyára; Budapest

Data
Forum
Pictures
Collections

  • Year
  • 1967–1969
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 170298

 Technical Specifications

  • Number of Tubes
  • 12
  • Valves / Tubes
  • Number of Transistors
  • 7
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Wide Band V.T. Voltmeter 1324 / TR-1301 - EMG, Orion-EMG, Elektronikus M
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 200 x 265 x 365 mm / 7.9 x 10.4 x 14.4 inch
  • Notes
  • 100 mikroV - 30 V +/-3%, 1 kHz - 30 MHz.
  • Net weight (2.2 lb = 1 kg)
  • 10 kg / 22 lb 0.4 oz (22.026 lb)
  • Source of data
  • -- Original-techn. papers.
  • Literature/Schematics (1)
  • EMG Katalog 1967.
