- Country
- Germany
- Manufacturer / Brand
- Elowi; Locher KG, Ernst; Kenzingen/Schwarzwald
- Year
- 1972
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 261661
ELOWI MTX 4000
ELOWI MTX4000 Innenansicht
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 60
- Semiconductors
- SF8636 AF124 BSX5313 µA703 BF224 BC237 BC308 TBA651 BC413 BC148 BC157 BC158 AC151 BC207 BC208 BC177 BC141 BD139 BD140 2N3055 BB104 AA112 AA143 AA119
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Tuned circuits
- 5 AM circuit(s) 15 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 100 W (120 W max.)
- Material
- Various materials
- from Radiomuseum.org
- Model: MTX-4000 - Elowi; Locher KG, Ernst;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 579 x 125 x 274 mm / 22.8 x 4.9 x 10.8 inch
- Notes
-
Der Receiver Elowi MTX-4000 ist im Empfangsteil mit Görler-Baugruppen (UKW-Mischteil, FM-ZF-Verstärker, Rauschsperre, Stereo-Decoder) ausgestattet.
AM-ZF-Verstärker enthält zusätzlich 2 Piezo-Filter.2 Endstufen mit je 50 W Sinus-Dauertonleistung.
Ausführung: Lieferbar in Nußbaum oder Schleiflack weiss mit wahlweise weiss oder schwarz eloxierter Blende.
Halbleiter jeweils nur einmal pro Typ gelistet.
- Net weight (2.2 lb = 1 kg)
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Price in first year of sale
- 1,200.00 DM
