Ela MOT729
Unitra ELTRA; Zaklady Radiowe; Bydgoszcz
- Country
- Poland
- Manufacturer / Brand
- Unitra ELTRA; Zaklady Radiowe; Bydgoszcz
- Year
- 1976
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 108607
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 3
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Ela MOT729 - Unitra ELTRA; Zaklady Radiowe;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 110 x 68 x 28 mm / 4.3 x 2.7 x 1.1 inch
- Notes
-
LW: nur 227 kHz - sender Warszawa I
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
