Stereo-Encoder SE100
ELV Elektronik AG; Leer (Ostfriesland)
- Country
- Germany
- Manufacturer / Brand
- ELV Elektronik AG; Leer (Ostfriesland)
- Year
- 2005
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 316235
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Special principle (see notes)
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit. / DC 12 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Stereo-Encoder SE100 - ELV Elektronik AG; Leer
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 140 x 60 x 26 mm / 5.5 x 2.4 x 1 inch
- Notes
-
Der Stereo-Encoder SE100 generiert aus einem Stereo-Audiosignal das für UKW-Stereo-Sendungen notwendige Stereo-Multiplexsignal.
- NF-Frequenzgang: 20 Hz bis 15 kHz
- Kanaltrennung: typ. 40 dB
- Klirrfaktor: typ. 0,07 %
- Ausgabgspegel: wahlweise 50 mVss oder 775 mVeff = 0 dBm
- Spannungsversorgung: 12 VDC
- Stromaufnahme: 20 mA
- Net weight (2.2 lb = 1 kg)
- 0.120 kg / 0 lb 4.2 oz (0.264 lb)
- Price in first year of sale
- 38.50 Euro
