• Country
• Greece

• Manufacturer / Brand
• Elvira - Ελβιρα (ΕΛ.ΒΙ.ΡΑ.), Ελληνική Βιομηχανία Ραδιοφώνων (Greek Radio Industry); Athens

• Year
• 1950 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 352331

• Number of Tubes
• 5

• Valves / Tubes
• 12SA7GT 12SK7GT 12SQ7GT 50L6GT 35Z5GT

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: B50 - Elvira - Ελβιρα ΕΛ.ΒΙ.ΡΑ., Ελλ

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 400 x 275 x 190 mm / 15.7 x 10.8 x 7.5 inch

• Net weight (2.2 lb = 1 kg)
• 5.7 kg / 12 lb 8.9 oz (12.555 lb)

• Author
• Model page created by Matthew Xenakis. See "Data change" for further contributors.

• Other Models

• Here you find 4 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Elvira - Ελβιρα (ΕΛ.ΒΙ.ΡΑ.), Ελληνική Βιομηχανία Ραδιοφώνων (Greek Radio Industry); Athens
