• Country
• United States of America (USA)

• Manufacturer / Brand
• Emerson Radio & Phonograph Corp.; New York, NY

• Year
• 1955 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 328692

• • alternative name: Emerson Television

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• 6BZ7 6U8 6CB6 6CB6 6CB6 6AL5 6CB6 6AU6 6AL5 12AX7 25L6GT 12SN7GT 12SN7GT 25BQ6GT 1B3GT 12AX4GT 6S4 17LP4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: 1060-F Ch=120239-F - Emerson Radio & Phonograph

• Notes

• Emerson model 1060D is a 14” b/w TV with US standard VHF tuner channels 2 thru 13.
  Equipped with chassis 120239-F, VHF tuner 470785 and picture tube 17LP4.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 275 Folder 7)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 291 Folder 1 Production Changes Bulletin 132 dated 10-55)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
