• Country
• United States of America (USA)

• Manufacturer / Brand
• Emerson Radio & Phonograph Corp.; New York, NY

• Year
• 1958

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 123988

• • alternative name: Emerson Television

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes
• 6BN4 6CG8 6CB6 6CB6 6CB6 6U8 6T8 6AQ5 12BY7A 6CG7 6CG7 6CU6 or 6DQ6A or 6DQ6 1B3GT 6AX4 6V6GT 5U4G 21BTP4 or 21ALP4B 12BE6 12BA6 12AT6 50C5 35W4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1280 Ch= 120360-E - Emerson Radio & Phonograph

• Shape
• Console with any shape - in general

• Notes

• Emerson model 1280 is a 21" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 120360-E, VHF tuner 471020 and picture tube 21BTP4A or 21ALP4B.
  Mahogany or blonde grained finishes, 4 speed record changer and AM receiver.



  Also available as Model Emerson TV-Phonoradio 1281 (UHF-VHF)

• Source of data
• -- Original prospect or advert

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 384 Folder 2 dated 1-58)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
