338

Emerson Radio & Phonograph Corp.; New York, NY

Data
Forum
Pictures
Collections

  • Year
  • 1940/1941
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 157437
    • alternative name: Emerson Television

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Line / Batteries (any type) / AC/DC 110; Batt. 90 & 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: 338 - Emerson Radio & Phonograph
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 325 x 310 x 135 mm / 12.8 x 12.2 x 5.3 inch
  • Notes

  • The Emerson portable model 338 uses tan/blue leatherette, which is an other technique than the "simulated leather" which uses cardboard instead of wood. See Emerson model 461.

  • Author
  • Model page created by Hans De Seijn. See "Data change" for further contributors.
