- Country
- United States of America (USA)
- Manufacturer / Brand
- Emerson Radio & Phonograph Corp.; New York, NY
- Year
- 1949 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 204415
-
- alternative name: Emerson Television
Skala und ein Drehknopf fehlt
Gleichrichter-Röhre 35W4 fehlt
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 50A-1 - Emerson Radio & Phonograph
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 280 x 160 x 140 mm / 11 x 6.3 x 5.5 inch
- Source of data
- - - Data from my own collection
- Author
- Model page created by Siegmar Mey. See "Data change" for further contributors.
