609 Ch= 120084B

• Country
• United States of America (USA)

• Manufacturer / Brand
• Emerson Radio & Phonograph Corp.; New York, NY

• Year
• 1949/1950

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 214712

• • alternative name: Emerson Television

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 30

• Valves / Tubes
• 6AG5 6J6 6AU6 6AU6 6AU6 6AU6 6AL5 6AU6 6AQ5 12AU7 12AU7 6SN7GT 6AL5 6SN7GT 6BG6G 5V4G 6SN7GT 6K6GT 6AU6 6AU6 6S8GT 6V6GT 6SC7 5Y3GT 6SR7 6BG6G EY51 EY51 EY51 3NP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 609 Ch= 120084B - Emerson Radio & Phonograph

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• The Emerson 609 is a 12" x 16" b/w projection screen TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 120084B, VHF tuner 470452 and a 4"picture tube 3NP4. Has separate high voltage unit.

• Price in first year of sale
• 599.50 $

• Literature/Schematics (1)
• - - Manufacturers Literature

• Literature/Schematics (3)
• Emerson Folder Form. No. 50-628 for "New 1950".

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
