878B Ch= 120267B
Emerson Radio & Phonograph Corp.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Emerson Radio & Phonograph Corp.; New York, NY
- Year
- 1957 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 230900
-
- alternative name: Emerson Television
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / AC/DC: 117=105-125 or Battery pack: 7.5 & 67,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
- Power out
- 0.3 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 878B Ch= 120267B - Emerson Radio & Phonograph
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 210 x 170 x 90 mm / 8.3 x 6.7 x 3.5 inch
- Notes
-
Emerson model 878B is a three power portable AM receiver.This model is burgundy whereas model 833 is green.
- Net weight (2.2 lb = 1 kg)
- 1.3 kg / 2 lb 13.8 oz (2.863 lb)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 381; Folder 7)
- Author
- Model page created by Dick Leijenaar. See "Data change" for further contributors.
