- Country
- Spain
- Manufacturer / Brand
- Emerson Electrónica, CECSA, Teinelsa; Barcelona
- Year
- 1971
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 277610
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- 15
- Semiconductors
- BF200 BF182 BF180 BF181 BF194 BF196 BF197 BF197 BC107 BF258 BC147 BC147 BC147 BC147 BF120 TAA550 TAA790 TBA120 OA90 OA91 B30C250 BA182 BB105 BB106 BY126 BZX46 E30C120 SFD86 TV18 1N914
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110-235 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Albany - Emerson Electrónica, CECSA,
- Shape
- Tablemodel, low profile (big size).
- Notes
-
TRC: 20". VHF/UHF con sintonía electrónica.
Fabricado por CECSA.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
