• Country
• Spain

• Manufacturer / Brand
• Emerson Electrónica, CECSA, Teinelsa; Barcelona

• Year
• 1971

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 259716

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors
• SC109 SC109 SC109 SC109 SC109 MC150 AD161 AD162 SC109 SC109 SC109 SC109 SC109 MC150 AD161 AD162 SC108 SC108 AC188 AC188 AC188 AA135 BZY87 OA91

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Special Tape or Cassette-Format

• Power type and voltage
• Alternating Current supply (AC) / 127; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 10 W (undistorted)

• Material
• Various materials

• from Radiomuseum.org
• Model: Playsonic Amplifier Stereo 8 - Emerson Electrónica, CECSA,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 420 x 125 x 200 mm / 16.5 x 4.9 x 7.9 inch

• Notes

• Este equipo es idéntico, con las variaciones externas de marca y tipografía, al Kolster 8 Trak Stereo Sound Playsonic. Ambos fabricados por CECSA.

• Mentioned in
• Esquemario de Magnetófonos y Cassettes. REDE. Tomo V/1977

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
