888

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Emerson Electronics Ltd; London

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 127067

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC44 OC45 OC45 OC71 OC72 OC72

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / AA: 4 X 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 888 - Emerson Electronics Ltd;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 105 x 167 x 50 mm / 4.1 x 6.6 x 2 inch

• Notes
• No tuning on the LW band, pre-set to one station only

• Net weight (2.2 lb = 1 kg)
• 0.636 kg / 1 lb 6.4 oz (1.401 lb)

• Price in first year of sale
• 15.00 GBP

• Source of data
• -- Original-techn. papers.

• Literature/Schematics (1)
• Trader Sheet 1471

• Author
• Model page created by Keith Staines. See "Data change" for further contributors.
