2 Band - 8 Transistor EP-822
EPEO (brand)
- Country
- Worldwide
- Manufacturer / Brand
- EPEO (brand)
- Year
- 1962 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 306945
- Number of Transistors
- 8
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Dry Batteries / AA: 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 0.2 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 2 Band - 8 Transistor EP-822 - EPEO brand
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 152 x 85 x 30 mm / 6 x 3.3 x 1.2 inch
- Notes
-
controllo volume - antenna interna in ferrite - commutatore SW/MW - n.2 prese per auricolare - presa per alimentazione esterna 4,5 volt DC - antenna telescopica esterna - frequency range: MW 540/1600 kHz - SW 3,8/10 MHz.
Made in Japan.
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
