KY-567M (Modern)
Erres, Van der Heem NV; Den Haag
- Country
- Netherlands
- Manufacturer / Brand
- Erres, Van der Heem NV; Den Haag
- Year
- 1956
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 248557
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 453/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 200; 220; 250 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3.2 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: KY-567M - Erres, Van der Heem NV; Den
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 558 x 365 x 242 mm / 22 x 14.4 x 9.5 inch
- Notes
-
FM: 86 - 101 MHz.
SW: 15.5 - 52 m.
MW: 186 -580 m.
LW: 1000 - 2000 m
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Author
- Model page created by Daniel Rosha. See "Data change" for further contributors.
