• Country
• Italy

• Manufacturer / Brand
• Eterphon; Torino

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 171576

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCH42 12BA6 12AT6 UL41 EM34 UY41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: K110 - Eterphon; Torino

• Shape
• Tablemodel, low profile (big size).

• Notes

• Attenzione: I filamenti delle valvole sono collegati sul primario del trasformatore di alimentazione, quindi direttamente alla rete elettrica!
  Non tutti i casi sono dichiarati poichè spesso chi propone il modello non lo può sapere.
  Controllo di tono. Ingresso Fono.

• Author
• Model page created by Pierantonio Ganazzin. See "Data change" for further contributors.
