K35
Eterphon; Torino
- Country
- Italy
- Manufacturer / Brand
- Eterphon; Torino
- Year
- 1955/1956
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 114041
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 471 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 120; 140; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (unknown quality)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: K35 - Eterphon; Torino
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 270 x 170 x 140 mm / 10.6 x 6.7 x 5.5 inch
- Notes
-
Stesso chassis Magnadyne A22 e Kennedy K422. Serie ANIE.
Autotrasformatore: Telaio collegato alla rete elettrica. Non tutti i casi sono dichiarati poichè spesso chi propone il modello non lo può sapere.
- Source of data
- Guida Pratica Antique Radio IV (2001)
- Literature/Schematics (1)
- -- Schematic (D.E. Ravalico, Il Radiolibro, 16° edizione, 1957, Hoepli)
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
