Radiolampada

• Country
• Italy

• Manufacturer / Brand
• Europhon; Milano

• Year
• 1970–1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 110088

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• BF344 BF345 BF345 BC108 AC138 AC141 AC142 AA121

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 0.5 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Radiolampada - Europhon; Milano

• Shape
• Design Radio or Novelty / Gadget - fancy or unusual shape.

• Dimensions (WHD)
• 165 x 230 x 165 mm / 6.5 x 9.1 x 6.5 inch

• Notes

• Radio per AM onde medie con lampada.

  Disegno di Adriano Rampoldi.

  Radio "da comodino" prodotta  in diversi colori. Massima potenza della lampada 40 W, con interruttore per normale/bassa luminosità.

• Net weight (2.2 lb = 1 kg)
• 1.4 kg / 3 lb 1.3 oz (3.084 lb)

• Price in first year of sale
• 12,300.00 ITL

• Mentioned in
• catalogo anie radio televisione elettroacustica 1971 1972

• Author
• Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
