945 portable
Europhon; Milano
- Country
- Italy
- Manufacturer / Brand
- Europhon; Milano
- Year
- 1972/1973 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 215888
- Number of Transistors
- Semiconductors present.
- Semiconductors
- TBA820
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 220 / (6 x 1,5) Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 945 [portable] - Europhon; Milano
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 290 x 185 x 75 mm / 11.4 x 7.3 x 3 inch
- Notes
-
Speaker elliptical, 18 cm x 8 cm, 4 ohms. All the signs are in German. UKW 88-104 MHz, KW 31-49 m. Power button. Volume and tone knobs.
Aesthetically and also for specifications corresponds to the model Quelle Universum 3 Band Kofferradio 26385, version Holzdekor.
Altoparlante elittico, cm 18 x 8, 4 ohm. Tutte le scritte sono in tedesco. UKW 88-104 MHz, KW 31-49 m. Tasto di accensione. Manopole di volume e tono. Corrisponde esteticamente e anche per caratteristiche tecniche al modello della Quelle Universum 3 Band Kofferradio 26385, versione Holzdekor.
Fonte catalogo ANIE 1972-73
- Net weight (2.2 lb = 1 kg)
- 1.8 kg / 3 lb 15.4 oz (3.965 lb)
- Author
- Model page created by Felice Nicolini. See "Data change" for further contributors.
