• Country
• Portugal

• Manufacturer / Brand
• Eurorádio; Lisboa

• Year
• 1973 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 129067

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 2 × 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Multitester M-500 - Eurorádio; Lisboa

• Dimensions (WHD)
• 95 x 140 x 40 mm / 3.7 x 5.5 x 1.6 inch

• Notes
• Multitester ranges:
  AC: 0 to 1000 V (10 kΩ/V)
  DC: 0 to 5000 V (20 kΩ/V)
  DC Current: 0 to 500 mA
  Resistence: 0 to 12 MΩ
  Decibels: -20 to +62 dB.

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Price in first year of sale
• 620.00 PTE

• Source of data
• - - Data from my own collection

• Author
• Model page created by Carlos Alves. See "Data change" for further contributors.
