Milady
FAART (F.A.A.R.T.); Milano
- Country
- Italy
- Manufacturer / Brand
- FAART (F.A.A.R.T.); Milano
- Year
- 1965 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 175006
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Milady - FAART F.A.A.R.T.; Milano
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 270 x 200 x 80 mm / 10.6 x 7.9 x 3.1 inch
- Net weight (2.2 lb = 1 kg)
- 2 kg / 4 lb 6.5 oz (4.405 lb)
- Price in first year of sale
- 40,500.00 ITL
- Mentioned in
- Catalogo ANIE 1965-66
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
- Other Models
-
Here you find 15 models, 7 with images and 6 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from FAART (F.A.A.R.T.); Milano
Collections
The model Milady is part of the collections of the following members.
