- Country
- United States of America (USA)
- Manufacturer / Brand
- Fada Radio & Electric Co.; Long Island (NY)
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 276064
-
- alternative name: Andrea-Radio || Nater, Henri, Atlanta-Radio; Zürich
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- 6BZ7 6AF4 6U8 6CB6 6CB6 6CB6 6CB6 or 6AN8 6U8 6T8 6AR5 or 6K6GT 6C4 or 6AN8 12BH7 6SN7GT 6BQ6GT or 6CU6 6AX4GT 1B3GT 5U4G 21YP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: DL400T - Fada Radio & Electric Co.;
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The FADA model DL400T is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF equipped with VHF-UHF tuner model 42.98 and picture tube 21YP4A.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 332 Folder 6 dated 10-56)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
