• Country
• United States of America (USA)

• Manufacturer / Brand
• Fada Radio & Electric Co.; Long Island (NY)

• Year
• 1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 39832

• • alternative name: Andrea-Radio || Nater, Henri, Atlanta-Radio; Zürich

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A8G 6K7 6Q7G 25L6G 25Z5

• Main principle
• Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: S-46G [Gold Trim] - Fada Radio & Electric Co.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 11 x 7.25 x 6 inch / 279 x 184 x 152 mm

• Notes

• BC (540 - 1720 kHz) band. 115.41 ballast. "Silent Radio" Ivory Plaskon and golden metal trim. Comes with Acousticon "Mystic Ear" pillow speaker.

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 10 = 1939 and before

• Mentioned in
• Machine Age to Jet Age III
