- Country
- United States of America (USA)
- Manufacturer / Brand
- Fada Radio & Electric Co.; Long Island (NY)
- Year
- 1951 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 347783
-
- alternative name: Andrea-Radio || Nater, Henri, Atlanta-Radio; Zürich
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 22
- Valves / Tubes
- 6CB6 or 6AK5 6J6 6AU6 6AU6 6CB6 or 6AU6 or 6AG5 or 6BC5 6AL5 6AG7 6AU6 6AL5 or 6T8 7B6 or 6AT6 6K6GT 12AU7 6SN7GT or 6J5 6S4 6AL5 6SN7GT 6CD6G 6W4GT 1B3GT 5U4G 5U4G 17BP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: S9C10 - Fada Radio & Electric Co.;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Fada model S9C10 is a 17” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with VHF tuner 42.64 or 42.55 and picture tube 17BP4A.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 134, folder 7, dated 5-51)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
