VHF Selector de Canales - Channel Selector / Tuner 1T20

Fagor Electrónica; Aspes; Mondragón, Guipúzcoa

Data
Forum
Pictures
Collections

  • Year
  • 1968 ??
  • Category
  • Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
  • Radiomuseum.org ID
  • 316156

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 3
  • Semiconductors
  • Main principle
  • RF Converter/Adapter (not voltage converter); ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Powered by external power supply or a main unit. / DC: 12 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: VHF Selector de Canales - Channel Selector / Tuner 1T20 - Fagor Electrónica; Aspes;
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Fagor 1T20 Selector de VHF para TV

    Selector VHF con transistores de silicio con adaptador de CAG (no representado, véase en 1T204)

  • Literature/Schematics (1)
  • -- Schematic
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
