58 Chassis Only
Fairbanks, Morse & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Fairbanks, Morse & Co.; Chicago (IL)
- Year
- 1936/1937
![perfect model](/img/sternRot.gif)
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 296260
-
- alternative name: FMC
- Brand: Welco
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 60Hz, 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 3 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 58 [Chassis Only] - Fairbanks, Morse & Co.;
- Shape
- Chassis only or for «building in»
- Notes
-
The Fairbanks Morse 58 is an AC operated, 5 tube BC, Police and SW band chassis used in models 58-C-1, 58-T-1 and 58-T-2. Has AGC and 2 stage audio circuit. The three bands cover a frequency tuning range of 540 to 23000kHz. Has 5.5" tuning dial, AVC and a tuning ratio of 8:1.
NOTE: 58 is the chassis number and NOT the model number. Please post pictures of the radio's on the appropriate radio model page and NOT to this page.
The following models use the same chassis:
Model Number Chassis Cabinet 58-C-1 58 Console 58-T-1 58 Table Model 58-T-2 58 Table Model
- Literature/Schematics (1)
- Rider's Perpetual, Volume 8 = 1937 and before (Fairbanks Morse section, pages 8-23, 8-24)
- Literature/Schematics (2)
- Gernsback Official Radio Service Manual (Volume 7, page 185)
- Literature/Schematics (3)
- - - Manufacturers Literature (Fairbanks-Morse Radio Service Notes Model 58 Chassis)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
