Capehart 36P10
Farnsworth Television & Radio Corp. - see also Capehart
- Country
- United States of America (USA)
- Manufacturer / Brand
- Farnsworth Television & Radio Corp. - see also Capehart
- Year
- 1948–1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 40037
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 455 & 1070 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Power out
- 8 W (unknown quality)
- from Radiomuseum.org
- Model: Capehart 36P10 - Farnsworth Television & Radio
- Notes
-
Built in AM loop antenna. Record changer P-73.
See here the "Common information for the Capehart model pages for the 1930s and 1940s".
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 22, covering 1951
