• Country
• United States of America (USA)

• Manufacturer / Brand
• Farnsworth Television & Radio Corp. - see also Capehart

• Year
• 1946–1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 40027

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 25

• Valves / Tubes
• 6SK7 6J5 6SA7 6SK7 6AF6 6SK7 6H6 6AG5 6C4 6AG5 6SK7 6SK7 6SK7 6H6 6SN7 6J7 6SN7 6J5 6J5 6J5 6J5 6L6G 6L6G 5U4G 5U4G

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Panamuse 26N2 Modern - Farnsworth Television & Radio

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 36 x 38.75 x 22.25 inch / 914 x 984 x 565 mm

• Notes

• Rectifier tube is 5U4G or 5V4G. Record changer P-63. See here the "Common information for the Capehart model pages for the 1930s and 1940s".

• External source of data
• Ernst Erb

• Mentioned in
• Rider's Perpetual, Volume 18 = covering late 1947 to early 1948 (Farnsworth 18-16 to 18-44)
