Renegade Powered Mixer 160 R

FBT Elettronica S.P.A.; Recanati (MC)

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 292708

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 120 W (200 W max.)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Renegade Powered Mixer 160 R - FBT Elettronica S.P.A.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 526 x 134 x 300 mm / 20.7 x 5.3 x 11.8 inch
  • Notes

  • FBT Renegade 160 R Powered Mixer: inputs: 4 x XLR jack mic/Line (balanced) - 1 x jack phono-Tape/CD - Sensivity: mic input max. gain 54 dB (XLR) - line input max gain 12 dB (jack) - CD/Tape max gain 12 dB (RCA Phono) - EQ control: +/- 15 dB 40 Hz - 14.000 Hz - phono record out - loudspeakers nominal impedance 8 Ω - cabinet Lightwight polypropylene - reverb effect.

    AF Power amplifier with thick film hybrid IC STK4044-II,

  • Net weight (2.2 lb = 1 kg)
  • 7.1 kg / 15 lb 10.2 oz (15.639 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
