Bassman 6G6 A

Fender Electric Instrument Co.; Fullerton (CA)

Data
Forum
Pictures
Collections

  • Year
  • 1962 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 337085

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Guitar Amplifier
  • Power type and voltage
  • Alternating Current supply (AC) / 110 Volt
  • Loudspeaker
  • 2 Loudspeakers / Ø 12 inch = 30.5 cm
  • Power out
  • 40 W (undistorted)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Bassman 6G6 A - Fender Electric Instrument Co.
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 22.25 x 8 x 9 inch / 565 x 203 x 229 mm
  • Notes

  • A tube amp designed specifically for bass guitars.

    Two input ranges: 2 x bass, 2 x normal.

    Rectifier consists of 2 x 3 diodes in series.

    The standby switch only switches off the anode voltage; the heaters remain on.

    Separate cabinet contains 2 - 12 inch diameter PM speakers.

    Dimensions of speaker cabinet are 32 inches wide x 21 inches high by 11.5 inches deep.



    Ein Röhren-Verstärker speziell für Bassgitarren.

    2 Eingangsbereiche: 2 x Bass, 2 x Normal.

    Gleichrichter besteht aus 2 x 3 Dioden in Reihe.

    Der Standby-Schalter schaltet nur die Anodenspannung ab, die Heizung bleibt an.



  • Net weight (2.2 lb = 1 kg)
  • 13 kg / 28 lb 10.1 oz (28.634 lb)
  • Author
  • Model page created by Andreas Sommerer. See "Data change" for further contributors.
