- Country
- Hungary
- Manufacturer / Brand
- Fénycső vilagítástechnikai és villamossági szövetkezet; Budapest
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 77382
-
- alternative name: Fenycsö Ksz.
Bitte mein vorheriges Upload
A magyar rádiózás története.., 1997.
Speaker cloth is not original.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 473.6 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110, 122, 150, 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Power out
- 2.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 55 - Fénycső vilagítástechnikai és
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 515 x 380 x 230 mm / 20.3 x 15 x 9.1 inch
- Notes
- Has the same chassis as Terta T331. Toggle switch for pick-up.
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Author
- Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
