- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London
- Year
- 1969 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 226552
-
- Brand: TRF
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 475/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.375 inch = 8.6 cm
- Power out
- 0.3 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 3165 - Ferguson Brand, Ferguson Radio
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Notes
-
Pocket sized AM/FM transistor radio with MW, LW and VHF (87.5 - 100MHz). Sockets for earphone and car aerial. PP7 9 volt battery.
- Source of data
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.)
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1945 dated 31 July 1970)
- Literature/Schematics (2)
- ERT Service Chart 1692 dated April 24 1969
- Author
- Model page created by Ernst Röggla. See "Data change" for further contributors.
