AM-FM Stereo Radiogram 3302
Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London
- Year
- 1962
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 169051
-
- Brand: TRF
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 6 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: AM-FM Stereo Radiogram 3302 - Ferguson Brand, Ferguson Radio
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- Stereo radiogram (radio is mono) fitted with BSR type UA16 record changer. Audio amplifier is Push-Pull mono for radio reception, but changes to 2 single stages for stereo. Price £54.11s.9d. plus tax.
- Price in first year of sale
- 55.00 GBP
- Source of data
- -- Schematic
- Literature/Schematics (1)
- Radio And Television Servicing books (R&TVS) (Trader Sheet 1705.)
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
