• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London

• Year
• 1951

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 196758

• • Brand: TRF

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• EF80 EF80 EF80 EF80 EF80 EB91 ECL80 PL81 PY80 EY51 EF80 EF80 ECL80 ECL80 PY82 MW31-16

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 988TS - Ferguson Brand, Ferguson Radio

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes
• 12 inch (29 cm) 405 lines b/w table TV with 5 channel GB standard VHF band I tuner for fringe areas. See also similar 988T standard table model.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
