• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London

• Year
• 1953

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 199843

• • Brand: TRF

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 23

• Valves / Tubes
• EF80 ECC81 EF80 EF80 EF80 EB91 PL83 ECL80 EB91 EF80 EF80 PL81 EY51 PY81 EF80 EBF80 ECL80 ECL80 ECL80 ECL80 PY82 PY82 MW36-24

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: 993T - Ferguson Brand, Ferguson Radio

• Shape
• Console with any shape - in general

• Notes
• Console TV set with a 14 inch 405 line b/w CRT which can be tuned into any of the 5 BBC regional channels broadcasting on VHF GB Band I.

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1095/T39)

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
