• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ferranti, GB

• Year
• 1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 79383

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EF85 EABC80 EM80 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 045 - Ferranti, GB

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 23 x 16.5 x 9.5 inch / 584 x 419 x 241 mm

• Notes
• One of the first AM/FM receivers. Magic Eye.

• Source of data
• Radio! Radio!

• Circuit diagram reference
• Radio and TV Servicing books (R&TVS) book

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
