RAD28

Fidelity Radio Co. Ltd.; London

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 346859

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 240 / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: RAD28 - Fidelity Radio Co. Ltd.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • Portable 3-Band Radio, Fidelity RAD28

    • Mains-Battery operated - integrated circuit
    • Carrying Handle
    • Earphone / Ext.LS Jack
    • Telescopic antenna
    • Power Consumption, 7 Watts



  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
