- Country
- Great Britain (UK)
- Manufacturer / Brand
- Fidelity Radio Co. Ltd.; London
- Year
- 1971 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 315001
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 15
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 470/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 8 W (max.)
- Material
- Various materials
- from Radiomuseum.org
- Model: RG33 - Fidelity Radio Co. Ltd.;
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1220 x 650 x 365 mm / 48 x 25.6 x 14.4 inch
- Notes
-
A transistorized stereo radiogram with a 3-band AM/FM tuner covering FM (87.5-102MHz), MW (540-1550kHz) and LW (150-250kHz) and a 4 speed BSR UA25 autochanger. Two 8 inch loudspeakers. Sockets provided for aerials, external loudspeakers and tape recorder.
- Net weight (2.2 lb = 1 kg)
- 25 kg / 55 lb 1.1 oz (55.066 lb)
- Literature/Schematics (1)
- Radio And Television Servicing books (R&TVS)
- Author
- Model page created by Bruno De Marchi. See "Data change" for further contributors.
