OBC 670 PD/RD 67770 / 67790

Finlux (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1978–1980 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 323268
    • alternative name: Iskumetalli Oy || Lohja Oy

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: OBC 670 PD/RD 67770 / 67790 - Finlux brand
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 744 x 509 x 470 mm / 29.3 x 20 x 18.5 inch
  • Notes

  • Finlux OBC 670 - 26 inch (67 cm) color TV with 16 programs.

    Voltage synthesis tuning, automatic contrast photoresistor (OBC, Optimum Brightness Contrast system), optional remote control and stand. Available with walnut, rosewood and white/black cabinet.

    Two versions:

    OBC 670 PD (model 67770) - without remote
    OBC 670 RD (model 67790) - with remote

    Made by Oy Lohja Ab Finlux.

  • Net weight (2.2 lb = 1 kg)
  • 37 kg / 81 lb 8 oz (81.498 lb)
  • Mentioned in
  • -- Original prospect or advert (Finlux prospect 1980)
  • Author
  • Model page created by Paolo Tarantino. See "Data change" for further contributors.
