• Country
• Finland

• Manufacturer / Brand
• Finlux (brand)

• Year
• 1983

• Category
• Miscellaneous (Other, Various) - see notes

• Radiomuseum.org ID
• 306531

• • alternative name: Iskumetalli Oy || Lohja Oy

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• SAA5041 SAA5030 SAA5020 SAA5052 µPD2114LC µPD2114LC SN74LS832 SN74LS161 SN74LS161 SN74LS02 BD153 BC557 BC547 SAA5012

• Main principle
• Special principle (see notes)

• Wave bands
• - without

• Power type and voltage
• Other, details in remarks or not known. / Fed from TV set Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Teletext addon module for ASA and Finlux TV chassies TX 03400511 - Finlux brand

• Dimensions (WHD)
• 182 x 25 x 102 mm / 7.2 x 1 x 4 inch

• Notes

• Finlux Teletext Decoder to be retrofitted into the following type of TV chassis:

  ASA: 56774, 56793, 67774, 67793, 56990, 67690
  Finlux: 56770/II, 56790/II, 67770/II, 67790/II, 56690, 67690

  Consists of main board Tx 03400511, IR decoder module TB 03400504, IR receiver 033004466, Remote control 03000760 and cables, accessories

  Semiconductors on main board: SAA5041 SAA5030 SAA5020 SAA5052 uPD2114 uPD2114 74LS83 74LS161 74LS161 74LS02 BD153 BC557B BC557B BC547B

  SAA5052 indicates Swedish character set.
  Semicondutors on IR decoder module: SAA5012 and BC547B
  Main board fed from TV chassi, internal regulators to 12V and 5V.
  Remote control uses 9V battery.



• Net weight (2.2 lb = 1 kg)
• 0.370 kg / 0 lb 13 oz (0.815 lb)

• Price in first year of sale
• 675.00 SEK

• Author
• Model page created by Anders Sandgren. See "Data change" for further contributors.
