• Country
• Hungary

• Manufacturer / Brand
• Finommechanikai Vállalat (FMV); Székesfehérvár

• Year
• 1972 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 122974

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Sztráda - Finommechanikai Vállalat FMV;

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 160 x 154 x 70 mm / 6.3 x 6.1 x 2.8 inch

• Net weight (2.2 lb = 1 kg)
• 1.6 kg / 3 lb 8.4 oz (3.524 lb)

• Literature/Schematics (1)
• Radio es Televizio Vevö keszülekek 1972-75

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
