- Country
- Hungary
- Manufacturer / Brand
- Finommechanikai Vállalat (FMV); Székesfehérvár
- Year
- 1962
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 124382
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Number of Transistors
- 3
- Main principle
- Superheterodyne (common); ZF/IF 473 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Gulliver - Finommechanikai Vállalat FMV;
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 156 x 130 x 73 mm / 6.1 x 5.1 x 2.9 inch
- Net weight (2.2 lb = 1 kg)
- 2.8 kg / 6 lb 2.7 oz (6.167 lb)
- Literature/Schematics (1)
- Radio es Televizio Vevö keszülekek 1964-66
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
